Summary
Yueqing Aiso LZZBJ4 35kV Post Model Current Transformer is used indoor, Usually installed in the vacuum circuit breaker for use. We can customize the level of accuracy and capacity according to the requirements of users.
LZZBJ4-35 high voltage power supply epoxy resin current transformer current transformer is epoxy resin casting fully closed product, suitable for rated frequency 50Hz or 60Hz, rated voltage 35KVpower system, for electric energy metering, current measurement and relay protection.
Type designation
Outline and installation dimension
Ratde primary current(A) | Accuracy class combination | Accuracy class / rated burden (VA) | 4S Thermal current(kA) | Rated dynamic stabiity curret(kA) | |
5-50 | 0.2S/0.5/10P10 0.2/0.5/10P10 0.2S/10P10/10P10 0.2/10P10/10P10 0.5/10P0/10P10 0.2S/0.5/10P10/0P10 0.2/0.5/10P10/0P10 02S/10P10/10P10/10P10 02/10P10/10P10/10P10 0.5/10P10/10P10/10P10 10P10/10P0/10P10 10P10/10P10/10P10/10P10 | 0.2S 0.2 | 15 | 3 | 7.5 |
0.5 | 25 | ||||
10P10 | 50 | ||||
75 | 0.2S 0.2 | 15 | 5 | 12.5 | |
0.5 | 25 | ||||
10P10 | 50 | ||||
100 | 0.2S 0.2 | 15 | 8 | 20 | |
0.5 | 25 | ||||
10P10 | 50 | ||||
150 | 0.2S 0.2 | 15 | 12 | 30 | |
0.5 | 25 | ||||
10P10 | 50 | ||||
200 | 0.2S 0.2 | 15 | 16 | 40 | |
0.5 | 25 | ||||
10P10 | 50 | ||||
300 400 | 0.2S 0.2 | 15 | 20 | 50 | |
0.5 | 25 | ||||
10P10 | 50 | ||||
600 | 0.2S 0.2 | 15 | 31.5 | 80 | |
0.5 | 25 | ||||
10P10 | 50 | ||||
800 1000 1200 1500 1600 | 0.2S 0.2 | 15 | 40 | 100 | |
0.5 | 25 | ||||
10P10 | 50 |
